a4-portable-wireless-thermal-printer
Overview
Features
Technical parameters
| Printing | Print method | Thermal-line dot method |
| Print speed | Max:250mm/s | |
| Resolution | 300dpi(8dots/mm) | |
| Effective printing area | 216mm | |
| Character | Character set | ASCII,GBK,BIG5 and so on |
| Print font |
ASCII:(9*17,9*24,16*18,12*24) Chinese:(24*24) |
|
| The characters number per line |
Font A(12*24):32 Font B(9*17):42 GBK:16 |
|
| Paper Roll specification | Paper type | Thermal paper roll |
| Paper width | 216mm | |
| Paper thickness | 55-200μm | |
| Max paper roll diameter/paper roll inner diameter | Max:150mm/Min:18mm | |
| Paper Feed method | Automatic feeding (straight out) | |
| detection | Head temperature detection | Thermistor |
| No Paper detection | Photoelectric detection | |
| Paper near end detection | Photoelectric detection | |
| Black mark detection | Photoelectric detection | |
| Seam Mark Detection | Photoelectric detection | |
| platen open detection function | Mechanical switch | |
| Baud rate | 9600bps-115200bps | |
| Instruction Set | EPSON ESC/POS Instruction Set | |
| Driver | Windows Driver | |
| Interface | USB,RS232,LAN | |
| Barcode | 1D code | UPCA,UPC-E,JAN13(EAN13),JAN8(EAN8),CODE39,ITF,CODABAR,CODE128,CODE93； |
| 2D code | QR code | |
| Reliability | Print Life | 100Km |
| Cutter life |
>1000000cuts (When cutting paper with thickness greater than 0.1mm, 500000cuts) |
|
| Cutter | Auto cutter | Support full cutter and half cutter simultaneously |
| Power | input | DC24V±10%,≥2A |
|
Environmental conditions |
Operating temperature | 0°C~50°C |
| Operating humidity | 20%RH ~85% RH | |
| Storage temperature | -20°C~60°C | |
| Storage humidity | 5% ~90%RH | |
| Overall dimension (wide * deep * high) | With presenter(paper roll diameter 150mm) | 114.8*157*234.3mm(without paper bezel) |
| Without presenter(paper roll diameter 150mm) | 114.8*157*233.8(without paper bezel) | |
| Without presenter(paper roll diameter 80mm) | 114.8*83*170.3mm (without paper bezel) |
Applications
FAQ
What is A4 portable wireless thermal printer?
The A4 portable wireless thermal printer is a portable printer that can easily connect to a variety of devices and print. It uses heat-sensitive technology for printing and can print documents the size of A4 paper.
What devices can this printer connect to?
The printer connects to computers, smartphones, tablets and other devices via Wi-Fi, USB and Bluetooth.
What are the printing options on this printer?
The printer can print black and white documents, supports single-sided printing, can print multiple pages and automatically save power. It can also print documents such as labels, business cards and pictures.
Is this printer easy to use?
Yes, this printer is very easy to use. It can easily connect to a device, install drivers, and print. In addition, it has a simple to use operation panel, can easily grasp the printing process.
What's the price of this printer?
The price of the printer varies depending on the retailer and the region where it is sold.
Does this printer have a warranty?
Yes, this printer usually comes with a one - to two-year warranty. The specific warranty policy depends on the seller and brand manufacturer.
